Rs Pro 1710850 95dB Through Hole Continuous Internal Piezo Buzzer, 23.5 (dia.) X 9.5mm, 3V Dc Min, 30V Dc Max
Technical Data Sheets
Specifications
Please select at least one specification below.
Mounting Type
Through Hole
Height
9.5 mm
Dimensions
23.5 (Dia.) x 9.5 mm
Diameter
23.5 mm
Drive Type
Internal
Minimum Operating Temperature
-20°C
Maximum Operating Temperature
+70°C
Minimum Supply Voltage
3V dc
Maximum Supply Voltage
30V dc
Sound Level
95 dB
Tone Type
Continuous
Maximum Frequency
3.9 kHz
Supply Current
30 mA
Minimum Frequency
2900 Hz
Product Description
S$ 156.40
(exc. GST)
S$ 170.48
(inc. GST)
Quantity:
EA
MOQ of 50 EA
Bundle of 50 EA
