FAN Specification
Size
80x80x25 mm
Mounting hole spacing
71,5x71,5 mm
Connector & pin-configuration
4-pin PWM
Cable length
20cm + 30cm NA-EC1 extension cable
Rotational speed (+/- 10%)
2200 RPM
Rotational speed with L.N.A. (+/- 10%)
1750 RPM
Min. rotational speed @ 20% PWM (+/-20%)
450 RPM
Airflow
55,5 m³/h
Airflow with L.N.A.
43,9 m³/h
Acoustical noise
17,7 dB(A)
Acoustical noise with L.N.A.
13,8 dB(A)
Input power (max.)
0,96 W
Input current (max.)
0,08 A
Operating voltage
12 V
Scope of delivery
Low-Noise Adaptor (L.N.A.)
4-Pin Y-Cable
30cm Extension Cable
4 Vibration-Compensators
4 Fan Screws
