Mean Well MDR-20-12 Mdr Switched Mode Din Rail Power Supply, 85 → 264V Ac Ac Input, 12V Dc Dc Output, 1.67A Output, 20W

Mean Well MDR-20-12 Mdr Switched Mode Din Rail Power Supply, 85 → 264V Ac Ac Input, 12V Dc Dc Output, 1.67A Output, 20W

Brand:	MEAN WELL
Model:	MDR-20-12

Product Description

MEAN WELL MDR-20-12 MDR Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 12V dc dc Output, 1.67A Output, 20W

Specifications

Description: AC-DC Industrial DIN rail power supply; Output 12Vdc at 1.67A; plastic case
Application: Installation UL 508 ITE EN/UL/IEC 60950
Technology: AC/DC
Power Format: DIN rail
Output Power (W): 20
Output Voltage (V): 12
Output Current (A): 1.67
Input Voltage (V): 110/230 universal input 90 - 264
IP Rating: No IP assigned
Width (mm): 22.5
Height (mm): 90
Depth (mm): 100
Control Signals: DC OK
Dimming Technology: No Dimming

S$ 37.20

(exc. GST)

S$ 40.55

(inc. GST)

Units	Discount	Unit Price
1 ~ 9	-	S$ 37.20
10 ~ 49	2% OFF	S$ 36.45
50++	19% OFF	S$ 30.00

Lead time of 6 working days required.

Item will be ready to dispatch within the lead time specified.

Quantity:

EA
