Introduction:

Jabsco Maxi Puppy 3000 can be mounted on any flat surface. Fit the pump in a dry, well ventilated position where there is full access for service. If installed in a vertical position the motor must be above the pump head. Use the rubber grommets provided to minimise vibration, do not overtighten the mounting screws.

Continuous rated, heavy duty pumps for bilge and general purpose use

ISO 8846 MARINE (Ignition protection).

ISO 8849 MARINE (Bilge pump standard).

Small bilge debris present no problem to these bronze bodied, flexible impeller pumps.

Simple design means fewer wearing parts. z 44 lpm (9.5 UK gpm) output @ 3m (10ft) head. z Self priming to 2.4m (8 ft).

Ports ½” BSP threaded (use ¾” hose adapters), plus connections for 25mm (1”) bore hose

• Connections: - for 25mm (1”) bore hose or 1/2" BSP
• Dimensions: - 220mm long, 120mm wide, 85mm high
• Fuse Size: - 25(amp)
• Output: - up to 45 litres/minute (10 gallons/minute).
• High capacity, continuously rated bilge pump
• Self priming up to 2.4m vertical lift
• Simple, fully serviceable design with few wearing parts
• Can generate pressures up to 1 bar (15 psi)
• Bronze body, stainless steel shaft
• Packaged Dimensions: L:28.00 x H:13.00 x W:15.00cm
• Actual Weight: 3.85 Kg  (Approx. 4.35 Kg packed)
