Product Description
RONG FU Drilling & Milling Machine RF-31
Technical Data :
- Model : RF-31
- Drilling : 32 mm (1")
- Face mill : 76 mm (3")
- End mill : 20 mm (3/4")
- Tapping (optional) : 16 mm (5/8")
- In light allioy : 32 mm (1")
- Motor 1 1/2 HP, 3 PH
- 1 speed motor (standard) @60 Hz : 115 – 3000 rpm
- 1 speed motor (standard) @50 Hz : 125 – 2500 rpm
- 2 speed motor (standard) @60 Hz : 75 – 3000 rpm
- 2 speed motor (standard) @50 Hz : 62 – 2500 rpm
- Spindle taper : MT3 or R8
- Spindle stroke : 130 mm
- Spindle nose to column surface : 205 mm
- Column diameter : 115 mm
- Working table : 730 x 210 mm
- Longitudinal travel : 430 mm
- Cross travel : 185 mm
- T-slot size : 16 x 26 mm
- Number of T-slots : 4
- Packing size (L x W x H) : 800 x 737 x 1143 mm (without stand)
- Net weight : 230 kg
- Gross weight : 255 kg
- 20′ container Q’ty : 42sets (without stand)
US $ 3,555.39
Lead time of 7 working days required.
Item will be ready to dispatch within the lead time specified.
Quantity:
EA
Stock:
5 EA in stock
In Seller's Warehouse
