Kacon KPL-BZ1R Buzzer 110VAC 22MM Red (while Stocks Last)
Product Description
Kacon KPL-BZ1R Buzzer 110VAC 22MM Red
The Kacon KPL-BZIR-110V is a red LED illuminated buzzer made for 22mm mounting holes. It gives an intermittent 80dB sound and is rated for 110V AC/DC. Buzzer sounds at approximately 1 second intervals. Rated IP 30
Specifications
- Dimensions- 64mm L x 30mm Diameter
- Sound Type- Intermittent
- LED Color- Red
- Voltage- 110V AC/DC
- Power Consumption- 20 mA
- Insulation Resistance- 100MOhm @ 500V DC
- LED Life- 50,000 Hrs
- Volume- 80 dB
- Ambient Temperature- -25 C to 55 C (-13 F to 131 F), No Freezing
- Terminal Bolt Driving Torque- 0.8N·m (8.16kgf·cm)
- Recommended Wire- 14-16 AWG Copper Wire
US $ 5.36
Quantity:
EA
Stock:
2 EA in stock
In Seller's Warehouse
