Features
- Precision Instrument for light luminance and colour
- Meet CIE photopic spectral response
- Colo temperature or Correlated colour temperature
- Custom reference value of colour difference model
- Lux or foot-candle unit selection
- Magnetic mount
Specification
Light Source
- Source selectable
Measuring Function
- Illuminance: Ev (lx or fcd)
- Color Coordinate: (x, y), (u', v') CIE 1960)
- Correlated Color Temperature: CT, ⊿uv
- Color Difference: (⊿Ev, ⊿x, ⊿y), (⊿Ev, ⊿u', ⊿v'), (⊿Ev,⊿CT,⊿u'v') (One set of reference color)
Measuring Range
- Ev: 0~80,000 lx (0~7,432 fcd)
- CT: 99,990 K Max.
Accuracy
- Ev: ± (3%+2 Digital) (3,000 lx, standard illuminant A measured)
- x, y: ± 0.02 (100 lx, RGB LED Light)
- CT: ± 4 %
Resolution
- Ev: 1 (0~9,999), 10 (Over 10,000), lx ; 0.1 (0.0~999.9),1(Over 1,000), fcd;
- CT: 1 (0~9,999), 10 (Over 10000), K; x, y: 0.001; u', v': 0.001
Response Time
- 1 sec Approx
Operation Temperature
- 0°C to 50°C (32°F to 122°F) Less than 80% RH
Dimension
- 140x49x29mm (instrument)
- 165x50x36mm(sensor)
Weight
- 200g
Accessories
- 9V Battery , Instruction manual , Carrying Case, Sleeve
