UbiBot
PT100 Industrial Temperature Probe
(-200℃ to +400℃) with 3m cable
for UbiBot IoT Device GS1 and Smart Plug SP1
(Model No.: PT100GS1)
Descriptions
This external probe is designed to use in extreme industrial conditions, such as steelworks, and oil refinery plants. It can work in a wide range of -200 to 400 Celsius degree. The material of the probe is 304 stainless steel that is erosion-resistant in mild acid or alkalescent liquids.
The Audio plug is designed for the UbiBot GS1 device and Smart Plug SP1.
The measurements are transferred to the devices, displayed on the large LCD screen, and synced to the platform via a network. So you can access the data instantly on the screen or remotely view them via our app or web console.
You can be notified when the probe readings go outside of the range you set previously. Therefore, you will have time to take action before damage happens.
Kindly reminder:
The external sensors are disabled by default. Please enable them in the "Settings" page on the App or the console after inserting the probe into the device. In this case, the readings from the external probe are accessible.
Features
- Works in extreme conditions
- Durable high quality material
- Integrated sensor with transmitter
- Design to pair UbiBot GS1 device and Smart Plug SP1
- Direct access to sensing readings
- 304 Stainless steel probe
Applications
- Steelworks
- Chemical Plant
- Oil Refinery Plant
- Food Making Factory
- Power Station
- Sewage Disposal
Specification:
- Temperature Range
- Range: -200°C to 400°C
- Accuracy: ±(2%+1℃)
- Steel Probe Length: 200mm
- Probe Diameter: Φ5mm
- Length of lead: 3 meters
- Buttcock line temperature range: -30°C to 200°C
- Probe Material: 304 Stainless Steel
- PT100 Transmitter Dimension: 85x60x33mm
- Connector: 3.5mm Audio Plug
- Nomial input voltage: 5V to 12V
- Output interface: 5V RS485
- Communication Protocol: Modbus RTU
- IP Rating: IP68
