Schneider Electric ZB4BP5 Head for Non Illuminated Push Button, Harmony XB4, Metal, Projecting, Yellow, 22mm, Spring Return, Booted, Unmarked
Schneider Electric ZB4BP5 Head for Non Illuminated Push Button, Harmony XB4, Metal, Projecting, Yellow, 22mm, Spring Return, Booted, Unmarked
| Brand: | SCHNEIDER ELECTRIC |
| Model: | ZB4BP5 |
Specifications
Please select at least one specification below.
Product or Component Type
Head for non-illuminated push-button
Range of Product
Harmony XB4
Standard
IEC 60947-5-5
CSA C22.2 No 14
IEC 60947-5-1
IEC 60947-1
UL 508
IEC 60947-5-4
JIS C8201-5-1
JIS C8201-1
Overvoltage Category
Class I conforming to IEC 60536
IP Degree of Protection
IP66 conforming to IEC 60529
IP67
Ambient Air Temperature for Operation
-40…70 °C
Mechanical Durability
10000000 cycles
Shape of Signaling Unit Head
Round
Cap/Operator or Lens Colour
Yellow
Operator Additional Information
Clear boot
Bezel Material
Chromium plated metal
Device Short Name
ZB4
This spec is not available in the specification table.
Ambient Air Temperature for Storage
-40…70 °C
This spec is not available in the specification table.
Device Presentation
Basic element
This spec is not available in the specification table.
Certifications
GL
CSA
BV
UL listed
DNV
LROS (Lloyds register of shipping)
This spec is not available in the specification table.
IK Degree of Protection
IK06 conforming to IEC 50102
This spec is not available in the specification table.
Product Compatibility
not compatible with legend holder
This spec is not available in the specification table.
Shock Resistance
30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
This spec is not available in the specification table.
Vibration Resistance
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
This spec is not available in the specification table.
Electrical Composition Code
C1 for <9 contacts using single blocks in front mounting
C2 for <9 contacts using single and double blocks in front mounting
C11 for <3 contacts using single blocks in front mounting
C15 for <1 contacts using single blocks in front mounting
This spec is not available in the specification table.
Protective Treatment
TH
This spec is not available in the specification table.
NEMA degree of Protection
NEMA 13
NEMA 4X
This spec is not available in the specification table.
Mounting Diameter
22.5 mm
This spec is not available in the specification table.
Type of Operator
spring return
This spec is not available in the specification table.
Operator Profile
Yellow projecting, unmarked
This spec is not available in the specification table.
CAD Overall Width
30 mm
This spec is not available in the specification table.
CAD Overall Height
30 mm
This spec is not available in the specification table.
CAD Overall Depth
35 mm
This spec is not available in the specification table.
Head Type
Standard
This spec is not available in the specification table.
Product Description
RM 38.92
| Units | Discount | Unit Price |
|---|---|---|
| 1 | - | RM 38.92 |
