Misumi GCPW20-4-8 Disc Couplings High Flexible, Double Disc

View Brand

Misumi GCPW20-4-8 Disc Couplings High Flexible, Double Disc

Brand:	MISUMI
Model:	GCPW20-4-8

Specifications

View other Shaft Couplings dimensions or variations

Length

28.8 mm

Body Material

Aluminum Alloy

Shaft Bore Diameter 1

4 mm

Shaft Bore Diameter 2

8 mm

Outer Diameter

20 mm

Allowable Torque Range

0.05 - 1.00 Nm

Shaft Tightening Method

Fastening Bolt

Shaft Bore Shape

Standard Bore

Single/Double

Double

Allowable Lateral Misalignment [mm]

Allowable Lateral Misalignment Range [mm]

0.02 - 0.2

Allowable Angular Misalignment [deg]

deg

Max. Rotational Speed [r/min]

10000

Series Name

Disc

Allowable Misalignment

Angular Misalignment / Eccentricity / Axial Misalignment

Max. Rotational Speed Range

4001 - 10000 r/min

Allowable Axial Misalignment

Product Description

RM 90.29

Quantity:

Stock:

20 EA in stock

In Seller's Warehouse

This item is sold by

SG-4887073424
