Specifications
Please select at least one specification below.
Material
SWP-A
Outer Diameter
8
mm
Allowable Load (Configurable Range)
30.01~60.00 N
Max. Load
41.19 N
Wire Diameter
1.2
mm
Free Length
30
mm
Length of Spring Used L+F
37.3
mm
Initial Tension
9.81 N
Standard Spring Constant
4.31 N/mm
Max. Deflection
7.3 mm
Hook Opposing Angle
180° (Standard)
Product Description
This item is sold by
SG-4887073424
