Rs Pro 5358461 70dB Panel Mount Fast Pulse Internal Piezo Buzzer, 42.5 (dia.) X 33mm, 6V ac/dc Min, 28V ac/dc Max
Rs Pro 5358461 70dB Panel Mount Fast Pulse Internal Piezo Buzzer, 42.5 (dia.) X 33mm, 6V ac/dc Min, 28V ac/dc Max
Brand:
RS Pro
Model:
5358461
Specifications
infotip-icon
View other Piezo Buzzers dimensions or variations
Please select at least one specification below.
Mounting Type
Panel Mount
Height
33 mm
Dimensions
42.5 (Dia.) x 33 mm
Diameter
42.5 mm
Drive Type
Internal
Minimum Operating Temperature
-30°C
Maximum Operating Temperature
+85°C
Minimum Supply Voltage
6V ac/dc
Maximum Supply Voltage
28V ac/dc
Sound Level
70 dB
Tone Type
Fast Pulse
Maximum Frequency
3.3 kHz
Supply Current
23 mA
Minimum Frequency
2300 Hz
