FEATURES

• Infinitely variable output pressure and flow

• Holds static pressure without generating heat or consuming power

• Standard models are suitable for oil or water applications

• Well proven and trouble-free operation

• Designed for ease of maintenance

• Low cost servicing

• Robust construction

PERFORMANCE DATA

Max Rated Output Pressure: 23,695psi (1,634bar)

Output Per Cycle: 4.5 in³ (74cc)

Max Flow: 558 in³/min (9 litre/min)

Max Air Supply Pressure: 100psi (7bar)

Ratio: 236 : 1

Air Consumption: 200 scfm (5,664 Nl/min)

CONSTRUCTION

Frame: Stainless Steel

Air Motor: Anodised Aluminium / Nitrile (Buna-N) Seals

Hydraulic Cylinder: Aluminium Bronze

Piston: Stainless Steel + Corrosion Resistant Chrome Finish

Outlet Port: Stainless Steel

L1** (standard): Brass / Copper Hydraulic Inlet, Air Inlet and Plated Steel Silencer

L2** (optional): Stainless Steel Hydraulic Inlet, Air Inlet and Silencer

CONNECTIONS

Hydraulic Inlet: 1/2" NPT(F)

Hydraulic Outlet: 9/16” HP(F)

Air Inlet: 3/4” BSPP(F)

Net Weight: 112kg (248lb)

COMMON OPTIONS (BUT NOT LIMITED TO)

/ A ATEX (94/9/EC) II 2GD c T5

/ F Panel mount digital stroke counter (non ATEX)

/ G Panel mount pneumatic stroke counter

/ I (over all dimension varies) Isolation valve

/ M Mild steel painted frame (Painted Blue) + Stainless steel tank (if applicable to the unit)

/ O (over all dimension varies) Single pen chart recorder complete with recorder isolation valve

/ R Relief valve

/ W Fitted with wheels

/ X Gauge protection guard
